Ball valves

Ball Valves NDV Japan Model F104NB

Price: Contact

  • Model: F104NB

    • Ball Valves NDV Japan Model F104NB

    Download Catalog

    DRAWING
    DIAPHRAGM VALVE
    SANATARY VALVE
    BALL VALVE
    BUTTERFLY VALVE
    ON-OFF BALL VALVE
    GENERAL CATALOG

  • Trademark: NDV
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Manually operated 2way ball valve / Ball Valves NDV Japan Model F104NB

    • Brand: NDV
    • Origin: Japan

    *The pictures and drawings in this website are only for references.Please contact our sales department for the details.

    Product Code F104NB
    Operation Manual operated(Lever type)
    Body Material Ductile iron(FCD)
    Lining Material -
    Balldisk Material SCS13A,14A,16A
    Diaphragm/Seat Material PTFE, Reinforced PTFE
    Range Of Nominal Diameter 15〜200
    End Connection Flange(JIS 10K)
    Remarks -

    Drawing Data Download

    Nominal Diameter Actuator Code Download
    B A
    1/2 15 - CAD Drawing
    3/4 20 - CAD Drawing
    1 25 - CAD Drawing
    1･1/2 40 - CAD Drawing
    2 50 - CAD Drawing
    2･1/2 65 - CAD Drawing
    3 80 - CAD Drawing
    4 100 - CAD Drawing
    5 125 - CAD Drawing
    6 150 - CAD Drawing
    8 200 - CAD Drawing



    Option:

    Product
    Code    		 Nominal
    Diameter    		 Model Operation Ancillary
    Device    		 Body
    Material    		 Lining
    Material    		 Diaphragm/
    Seat Material    		 End
    Connection
    F104NB 15〜200 2way Manual O.P.(Lever) × Ductile iron(FCD) × PTFE Flange(10K) Detail
    F104NB 15〜200 2way Manual O.P.(Lever) × Ductile iron(FCD) × PTFE + metal ring Flange(10K) Detail
    F104NB 15〜200 2way Manual O.P.(Lever) × Ductile iron(FCD) × Carbon + metal ring Flange(10K) Detail
    F104NB 15〜200 2way Manual O.P.(Lever) × Ductile iron(FCD) × Metal Flange(10K) Detail
