Ball valves

SS316 Ball Valves NDV Japan Model FG112NB / Manually operated 2way ball valve

Price: Contact

  • Model: FG112NB

    • SS316 Ball Valves NDV Japan Model FG112NB / Manually operated 2way ball valve

    Download Catalog

  • Trademark: NDV
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    SS316 Ball Valves NDV Japan Model FG112NB / Manually operated 2way ball valve

    *The pictures and drawings in this website are only for references.Please contact our sales department for the details.

    Product Code FG112NB
    Operation Manual operated(Gear type)
    Body Material CF8M - Stainless steel(SCS14)
    Lining Material -
    Balldisk Material SCS13A,14A,16A
    Diaphragm/Seat Material PTFE, Reinforced PTFE
    Range Of Nominal Diameter 15〜200
    End Connection Flange(JIS 10K)
    Remarks -

    Drawing Data Download

    Nominal Diameter Actuator Code Download
    B A
    4 100 - CAD Drawing
    5 125 - CAD Drawing
    6 150 - CAD Drawing
    8 200 - CAD Drawing





    FG112NB 100〜200 2way Manual O.P.(Gear) × Stainless steel(SCS14) × PTFE Flange(10K) Detail
    FG112NB 100〜200 2way Manual O.P.(Gear) × Stainless steel(SCS14) × PTFE + metal ring Flange(10K) Detail
    FG112NB 100〜200 2way Manual O.P.(Gear) × Stainless steel(SCS14) × Carbon + metal ring Flange(10K) Detail
    FG112NB 100〜200 2way Manual O.P.(Gear) × Stainless steel(SCS14) × Metal Flange(10K) Detail
