Ball valves

SS316 Ball Valves NDV Japan Model F112NB / Manually operated 2way ball valve

Price: Contact

  • Model: F112NB

    • Ball Valves NDV Japan Model F112NB / Manually operated 2way ball valve

    Download Catalog

  • Trademark: NDV
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Ball Valves NDV Japan Model F112NB / Manually operated 2way ball valve

    *The pictures and drawings in this website are only for references.Please contact our sales department for the details.

    Product Code F112NB
    Operation Manual operated(Lever type)
    Body Material Stainless steel(SCS14)
    Lining Material -
    Balldisk Material SCS13A,14A,16A
    Diaphragm/Seat Material PTFE, Reinforced PTFE
    Range Of Nominal Diameter 15〜200
    End Connection Flange(JIS 10K)
    Remarks -

    Drawing Data Download

    Nominal Diameter Actuator Code Download
    B A
    1/2 15 - CAD Drawing
    3/4 20 - CAD Drawing
    1 25 - CAD Drawing
    1･1/2 40 - CAD Drawing
    2 50 - CAD Drawing
    2･1/2 65 - CAD Drawing
    3 80 - CAD Drawing
    4 100 - CAD Drawing
    5 125 - CAD Drawing
    6 150 - CAD Drawing
    8 200 - CAD Drawing



    Product
    Code    		 Nominal
    Diameter    		 Model Operation Ancillary
    Device    		 Body
    Material    		 Lining
    Material    		 Diaphragm/
    Seat Material    		 End
    Connection
    F112NB 15〜200 2way Manual O.P.(Lever) × Stainless steel(SCS14) × PTFE Flange(10K) Detail
    F112NB 15〜200 2way Manual O.P.(Lever) × Stainless steel(SCS14) × PTFE + metal ring Flange(10K) Detail
    F112NB 15〜200 2way Manual O.P.(Lever) × Stainless steel(SCS14) × Carbon + metal ring Flange(10K) Detail
    F112NB 15〜200 2way Manual O.P.(Lever) × Stainless steel(SCS14) × Metal Flange(10K) Detail
