System Products

Steam Compressor - SC Series

Price: Contact

Model: SC Series

Trademark: TLV

Origin: Japan

Order

Project details Download Catalogue Evaluate

Steam Compressor

SC Series

Steam compressor that recovers low pressure steam at higher pressure for reuse

All too often, low-pressure waste steam and flash steam are simply released to atmosphere instead of being reused. This can be an unhealthy practice, since losing steam often means a loss of useable energy.

TLV’s Steam Compressor uses high efficiency ejector technology to recover and reuse this excess steam, leading to lower energy consumption and fuel costs. Incorporating a steam compressor is often a great choice to increase efficiency by reducing the need to vent steam to atmosphere.

Steam Compressor Unit / System Pamphlet (910 KB)

Benefits and Features

Reuses energy from excess steam by increasing it to useable pressure.
Features patented, highly efficient steam compression technology.
Can be purchased together with a condensate recovery package; condensate is first reduced to atmospheric pressure, causing it to flash into steam. The steam is then pressurized for reuse.
Features a pressure reducing valve with a built-in separator and steam trap, maintaining dry motive steam and ensuring long-term high efficiency.
Requires no electricity and is suitable for explosion-proof areas.

Recovery of Steam Even at Atmospheric Pressure

Highly efficient steam compression system that combines a steam ejector, a pressure reducing valve, and a built-in cyclone separator. Capable of recovering steam even at atmospheric pressure.*
*Requires the use of a COS or CV-COS control valve.

Ideal for Explosion-proof Areas

Requires no electricity and is suitable for explosion-proof areas. *
*Requires the use of a COS control valve.

Application Areas

Removing vapor clouds above tanks of boiling water
Pressurizing and reutilizing flash steam from tanks
Pressurizing and reutilizing excess steam used in power generation
Pressurizing and reutilizing low pressure steam generated after use in processes

Product Details

Model	Overview	Suction steam quantity¹⁾(t/h)	Catalogue
SC1	Maximizes steam utilization by recovering excess low pressure steam at a higher pressure resulting in reduced energy costs and CO₂ emissions.	0.05 - 0.55	Specifications
SC2		0.1 - 1.2	Specifications
SC7		0.1 - 2.8	Specifications
SC14		0.2 - 6.1	Specifications
SC21		0.3 - 10.3	Specifications
SC31		0.5 - 14.8	Specifications
