RUBBER JOINT

• BELLOW TYPE: SINGLE SPHERE / 1-SPHERE / 1-BELLOW
• BELLOW MATERIAL: SYNTHETIC RUBBER
  • Reinforcing Ring: Carbon Steel
  • Inner Rubber: Synthetic Rubber
  • Outer Rubber: Synthetic Rubber
  • Reinforcing Cord: Synthetic Fiber
• FLANGE MATERIAL: DUCTILE IRON / MID STEEL SS400, STAINLESS STEEL 304/ 316
• FLANGE STANDARD: JIS10K/ PN16/ ANSI150 (option)
• MAX PRESSURE: 16 KGF/CM2 (16 BAR)
• TEMPERATURE RANGE: -10ºC to 70ºC
• TOZEN-CHINA
• SIZE: 32A ~ 300A (DN32 ~ DN300)
• MODEL: OFLEX

• "TOZEN" RUBBER FLEXIBLE JOINT-SINGLE SPHERE-FLANGED ENDS JIS 10K,
• Material of Inner & Outer: Synthetic Rubber, Flange: Ductile Iron
• Application: Cold Water,Cooled Water,Warm Water, Sea Water, etc.
• Max pressure:10kgf/cm2; Temp:10 to 70Deg.C
