SF-6721 - Stainless Steel Flexible Joint Flanged End JIS10K Tozen Japan

• Type: No Welding (Non Welding Type)

• Material:

  • Inner: 304 stainless steel

  • Outer braided mesh: 304 stainless steel

  • Flange: SS400 steel - galvanized

  • Lap Ring: 304 . Stainless Steel

• Connection end: Flanged end JIS10K - Loose Flange Both ends

• Length: 300mm

• Maximum working pressure: 10 kgf/cm2 (10 bar)

• Maximum working temperature: 250oC

• Model: SF-6721

• Size: 65A ~ 300A (DN65 ~ DN300)

• "TOZEN" STAINLESS STEEL FLEXIBLE JOINT - FLANGED ENDS JIS10K

• Flexible SUS304, Flange :SS400

• Application: Water,Steam, Air, Oil... Max pressure:10Kgf/cm2 Max temp: 250Deg.C
