Stainless Steel Flexible Joint SF100 NW Tozen Japan

• Type: Non Welding Type
• Material:
  • Inner: 304 stainless steel
  • Outer braided mesh: 304 stainless steel
  • Threaded connector: cast iron FCMB
  • Gaskets & Necklaces: SS400
• Connection standard: BSPT Thread Both ends.
• Length: 300mm
• Maximum working pressure: 16 kgf/cm2 (16 bar)
• Maximum working temperature: 250oC
• Model: SF100-NW
• Size: 15A ~50A (DN15 ~ DN50)

• "TOZEN" STAINLESS STEEL FLEXIBLE JOINT- UNION TYPE
• Flexible: SUS304, Union : Ductile Iron
• Application: Water, Steam, Air, Oil. Max pressure:16Kgf/cm2 Max temp: 250Deg.C
