Jointing / Gasket Material

KLINGER Graphite - Laminate PSM - NON-Metallic Sheets & Gaskets

Price: Contact

  • Model: Laminate PSM

    • NON-Metallic Sheets & Gaskets

    KLINGER Graphite - Laminate PSM

    Project details Download Catalogue Evaluate

    KLINGER graphite-laminate PSM



    Technical data PSM 10010 PSM 15010 PSM 20010
    Density of graphite layer g/cm3 ca. 1,0 ca. 1,0 ca. 1,0
    Max. perm. surface load at 450℃ MPa 300 180 160
    Compressibility ASTM F 36 J % 28-33 33-38 35-40
    Recovery ASTM F 36 J % 14-19 13-18 13-18
    Stress relaxation DIN 52913
    50MPa, 16h/300℃ MPa Min.48 Min.48 Min.48
    KLINGER cold hot compression
    Surface load 50MPa
    Thickness decrease at 23℃ % 30 40 45
    Thickness decrease at 300℃ % 1.5 1.5 2.0
    Thickness according to DIN 3535 part 6 ml/min 0.6 0.8 1.0
    Chloride content of graphite layer ppm Max. 40 Max. 40 Max. 40
    Thickness mm 1.0 1.5 2.0
    Size of sheets mm 1,000/1.000 1,000/1.000 1,000/1.000
    mm 1,500/1.500 1,500/1.500 1,500/1.500
    Thickness : 0.8/1.0/1.5/2.0/3.0mm
