Graphite sheet and laminates

KLINGER® GRAPHITE LAMINATE SLF - Graphite Laminates

Price: Contact

  • Model: KLINGER® GRAPHITE LAMINATE SLF
  • Trademark: KLINGER
  • Origin: Australia
    • Project details Download Catalogue Evaluate

    KLINGER® GRAPHITE LAMINATE SLF

    High temperature gasket material with outstanding performance.

    • KLINGER® Graphite Laminate SLF combines easy handling with outstanding long term sealing performance. It complies with the German TA Luft (Clean-air).

    Basis

    • This material is composed of two layers of flexible graphite and a 0.3 mm thick high temperature resistant and firbre based insert.

    Areas of application

    • KLINGER® Graphite Laminate SLF is recommended for applications in which graphite is the material of choice and minimal fugitive emissions are required.

    Key features

    • Unique non-metallic reinforcement
    • Excellent chemical resistance
    • High temperature resistance

    CERTIFICATES & APPROVALS

    • TA-Luft (Clean air)

    Benefits

    • Easy to cut
    • Safe handling
    • Excellent tightness

    Dimensions of the standard sheets

    • Sizes: 1000 x 1500 mm
    • Thicknesses: 1.5 mm, 2.0 mm
    • Tolerances:
    • Thickness ±5 %
    • Length ±4 mm, Width ±4 mm

    Other graphite qualities, thicknesses and sizes on request.
