Compressed Fibre

KLINGERSIL® C-4509 - Non-Asbestos Gasket

Price: Contact

  • Model: KLINGERSIL® C-4500
  • Trademark: KLINGER
  • Origin: Australia
  • KLINGERSIL® C-4509

    Special high-pressure gasket for highest thermal and mechanical stresses.

    KLINGERSIL® C-4509 is a special high-pressure gasket for highest thermal and mechanical stresses. Due to the expanded metal reinforcement it offers a high stress capability and is suitable for high bolt loads. The basic material KLINGERSIL® C-4500 is a Fire Safe grade.

    Basis

    Carbon fibres and special high temperature resistant additives, bonded with NBR.

    Areas of application

    Made from high-tech materials it offers excellent service in many sectors of the chemical industry. Main fields of application: alkaline media and steam.

    Key features

    • Utilization of carbon fibres

    • Expanded metal reinforcement

    • Improved stress relaxation

    Benefits

    • Suitable for high-pressure applications

    • Higher resistance against blow-outs

    • More safety at high internal pressures

    CERTIFICATES & APPROVALS

    • German Lloyd

    Dimensions of the standard sheets

    Sizes KLINGERSIL® C-4509: 1000 x 1500 mm, 2000 x 1500 mm

    Sizes KLINGERSIL® C-4509 L: 1000 x 1230 mm, 2000 x 1230 mm

    Thicknesses: 1.0 mm, 1.5 mm

    Tolerances

    Thickness acc. to DIN 28091-1
    Length ±50 mm, Width ±50 mm
