Basis

• Aramid fibres bonded with NBR.

Areas of application

• Resistant to oils, water, steam, gases, salt solutions, fuels, alcohols, moderate organic and inorganic acids, hydrocarbons, lubricants and refrigerants.

Key features

• Universal high pressure gasket material
• Dimensionally stable
• Consistent material composition

Benefits

• Excellent Price/Performance ratio
• Suitable for many different media
• Very good resistance to refrigerants

Standard sheet dimensions

• Sizes: 1,000 x 1,500 mm; 2,000 x 1,500 mm
• Thicknesses: 0.5 mm, 1.0 mm, 1.5 mm, 2.0 mm, 3.0 mm

Tolerances:

• Thickness acc. DIN 28091-1,
• length ± 50 mm, width ± 50 mm

CERTIFICATES & APPROVALS

• BAM tested
• DIN-DVGW
• DIN-DVGW W 270
• DVGW VP 401
• Elastomer-Guideline
• ÖVGW Reg.No. G 1.912
• German Lloyd
• TA-Luft (Clean air)
• Fire-Safe acc. to DIN EN ISO 10497
