Other Products
Radiator Trap/Radiator Valve
TS-1A, TS-1S, TS-1HA, TS-1HS, TS-3A, TS-3S, TS-4A,TS-4S, FV-2A, FV-2S, HV-3
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-1A |
15A -25A (1/2"-1") |
Steam condensate | 100kPa | Screwed | Bronze | Radiator trap, 0.1MPa, angle |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-1S |
15A -25A (1/2"-1") |
Steam condensate | 100kPa | Screwed | Bronze | Radiator trap, 0.1MPa, straight |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-1HA |
25A (1") |
Steam condensate | 0.2MPa | Screwed | Bronze | Radiator trap, 0.2 MPa, angle, 25A |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-1HS |
25A (1") |
Steam condensate | 0.2MPa | Screwed | Bronze | Radiator trap, 0.2 MPa, straight, 25A |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-3A |
15A -20A (1/2"-3/4") |
Steam condensate | 0.2MPa | Screwed | Bronze | Radiator trap, 0.2 MPa, angle |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-3S |
15A -20A (1/2"-3/4") |
Steam condensate | 0.2MPa | Screwed | Bronze | Radiator trap, 0.2 MPa, straight |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-4A |
15A -20A (1/2"-3/4") |
Steam condensate | 0.35MPa | Screwed | Bronze | Radiator trap, 0.35 MPa, angle |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 TS-4S |
15A -20A (1/2"-3/4") |
Steam condensate | 0.35MPa | Screwed | Bronze | Radiator trap, 0.35 MPa, straight |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 FV-2A |
15A -32A (1/2"-1-1/4") |
Steam Water |
0.3MPa | Screwed | Bronze | Radiator valve, bellows seal, angle |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 FV-2S |
15A -32A (1/2"-1-1/4") |
Steam Water |
0.3MPa | Screwed | Bronze | Radiator valve, bellows seal, straight |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 HV-3 |
15A -20A (1/2"-3/4") |
Water | 0.6MPa | Screwed | Bronze | Radiator valve/return valve, straight |
