Air Operated Valve/Control Valve

Price: Contact

  • Model:

    •

  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Air Operated Valve/Control Valve

    CT-1, PD-3, KBLV-2SF, PD-1, PD-2, KBFV-1S

    DOWNLOAD CATALOG

    Model Nominal size Application Max. pressure End connection Body Material Feature

    CT-1


    CT-1    		 15A -100A
    (1/2"-4")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K
    EN flangeEN PN16
    ASME flange_ASME Class 150    		 Cast carbon steel Single seated globe control valve
    Model Nominal size Application Max. pressure End connection Body Material Feature
    PD-3
    PD-3    		 15A -50A
    (1/2"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 2.2MPa Screwed Stainless steel Stainless steel, air operated, angle seat ON-OFF valve
    Model Nominal size Application Max. pressure End connection Body Material Feature
    KBLV-2SF
    KBLV-2SF    		 15A -100A
    (1/2"-4")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1.4MPa JIS flange_JIS 10K
    EN flangeEN PN16
    ASME flange_ASME Class 150    		 Stainless steel Ball valve, stainless steel, ON-OFF
    Model Nominal size Application Max. pressure End connection Body Material Feature
    PD-1
    PD-1    		 15A -25A
    (1/2"-1")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Bronze Bronze, air operated ON-OFF valve
    Model Nominal size Application Max. pressure End connection Body Material Feature
    PD-2
    PD-2    		 15A -50A
    (1/2"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Cast iron Cast iron, air operated ON-OFF valve
    Model Nominal size Application Max. pressure End connection Body Material Feature
    KBFV-1S
    KBFV-1S    		 50A -150A
    (2"-6")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1.9MPa Wafer Stainless steel Butterfly valve, stainless steel, ON-OFF
