Air Vent Valve/Air Vent Valve with Vacuum Breaker

Price: Contact

  • Model:
  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Air Vent Valve/Air Vent Valve with Vacuum Breaker

    TA-3, TA-2, TA-3C, TA-3C-N, TA-2C, TA-18ML, TA-22ML, TA-16, TA-16L, TA-16CVA, TA-16CVS, TAV-2, TAV-4, VB-20

    DOWNLOAD CATALOG

    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-3
    TA-3    		 15A -32A
    (1/2"-1-1/4")    		 Water
    Oil    		 1MPa Screwed Ductile cast iron Standard model
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-2
    TA-2    		 15A -32A
    (1/2"-1-1/4")    		 Water
    Oil    		 1MPa Screwed Ductile cast iron Quick air ventilation
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-3C
    TA-3C    		 15A -32A
    (1/2"-1-1/4")    		 Water
    Oil    		 1MPa Screwed Ductile cast iron Nylon coating
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-3C-N
    TA-3C-N    		 15A -32A
    (1/2"-1-1/4")    		 Water 1MPa Screwed Ductile cast iron

    Nylon coating,

    JWWA approved
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-2C
    TA-2C    		 15A -32A
    (1/2"-1-1/4")    		 Water
    Oil    		 1MPa Screwed Ductile cast iron

    Quick air ventilation,

    nylon coating
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-18ML
    TA-18ML    		 6A -20A
    (1/8"-3/4")    		 Water 0.3MPa Screwed Stainless steel

    Stainless steel,

    hose connection
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-22ML
    TA-22ML    		 15A -25A
    (1/2"-1")    		 Water 1MPa Screwed Bronze Bronze, hose connection
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-16
    TA-16    		 15A -25A
    (1/2"-1")    		 Water 1MPa Screwed Stainless steel Stainless steel, 1.0 MPa
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-16L
    TA-16L    		 15A -25A
    (1/2"-1")    		 Water 1MPa Screwed Stainless steel

    Stainless steel,

    1.0MPa, hose joint
    Model Nominal size Application Max. pressure End connection Body Material Feature

    TA-16CVA


    TA-16CVA

    		 15A -25A
    (1/2"-1")    		 Water 1MPa Screwed Stainless steel

    Stainless steel, with

    check valve (angle)
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TA-16CVS
    TA-16CVS    		 15A -25A
    (1/2"-1")    		 Water 1MPa Screwed Stainless steel

    Stainless steel, with

    check valve (straight)
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TAV-2
    TAV-2    		 15A
    (1/2")    		 Water 1MPa Screwed Bronze

    Air vent with vacuum

    breaker
    Model Nominal size Application Max. pressure End connection Body Material Feature
    TAV-4
    TAV-4    		 20A -25A
    (3/4"-1")    		 Water 1MPa Screwed Bronze

    Air vent with vacuum

    breaker
    Model Nominal size Application Max. pressure End connection Body Material Feature
    VB-20
    VB-20    		 20A
    (3/4")    		 Water 1MPa Screwed Bronze JWWA approved
