Thermodynamic Steam Trap

Structure characteristics
1. It has the steam or air thermal insulation device, which will not be affected Dy the environmental humidity. It reduces the frequency of motion and lengthens the lifetime.
2. H ts equipped with filter and drain valve.
3.It is sensitive and reliable in operation with large capacity.

Working principle
Thermodynamics steam trap works by moving valve block ups and downs. When the valve block is jacked up, the condensation water will be drained out. And when the steam gets into it, the valve block will close tightly.

Main application
This type of steam trap is suitable for steam piping and steam equipment. It can prevent tho leakage of steam and dram condensation water,which thus can save energy and prevent water hammer situation and the trouble caused by it.





Structure characteristics
l. lt has tho steam or air thermal insulation device, which will not be affected by the environmental humidity. II reduces the frequency of motion and lengthens the lifetime.
2.lt K equipped with fitter and drain valve.
3.it is sensitive and reliable in operation with large capacity.

Main application
This type of steam trap is suitable for steam piping and steam equipment situation and the trouble caused by it

Specification
