🔷 What is a VINVAL Extended Tube Welded Ball Valve?

The VINVAL Extended Tube ANSI Welded Ball Valve is a high-performance industrial valve designed with a fully welded construction and an extended tube for easy operation in underground or hard-to-access installations.

With its forged steel body and optimized structure, the valve provides excellent sealing performance, high durability, and stable operation, making it ideal for high-pressure and demanding working conditions.

⚙️ Technical Specifications

• Size Range: 1/2” – 2”
• Pressure Rating: Class 150 – Class 2500
• Body Materials: ASTM A105N, A350 LF2
• Connection Type: Welded
• Temperature Range: -29°C to 425°C
• Design Standard: ASME B16.34

📐 Key Design Features

The VINVAL welded ball valve is engineered with advanced design advantages:

• Forged steel construction: High strength and pressure resistance
• Fully welded body: Eliminates leakage at connection points
• Extended tube design: Suitable for underground or difficult installations
• Compact structure: Ideal for limited installation space
• Customizable tube length according to customer requirements

⭐ Key Advantages

• ✔️ High pressure resistance up to Class 2500
• ✔️ Excellent sealing performance with extremely low leakage
• ✔️ Strong resistance to corrosion and wear, long service life
• ✔️ Low flow resistance, ensuring stable fluid flow
• ✔️ Easy operation and low maintenance
• ✔️ Suitable for a wide range of media and working conditions

🏭 Applications

The VINVAL extended tube welded ball valve is widely used in:

• Underground pipeline systems
• Oil & gas and petrochemical industries
• Power plants
• Gas, oil, and steam systems
• Applications requiring high sealing integrity and safety
