🔷 What is a VINVAL Forged 3PC Ball Valve?

The VINVAL Forged 3PC Ball Valve (F304L) is a high-performance industrial valve featuring a three-piece (3PC) design, allowing easy disassembly, maintenance, and replacement of internal components. Manufactured from high-quality forged stainless steel, the valve provides excellent durability, high pressure resistance, and near zero leakage performance.

It is ideal for applications requiring stable operation under high pressure, high temperature, and corrosive environments.

⚙️ Technical Specifications

• Size Range: 1/2” – 2”
• Pressure Rating: Class 150 – Class 2500 (Class 800 commonly used)
• Body Materials: F304, F316, F304L, F316L
• Connection Type: Butt Weld (BW)
• Temperature Range: -29°C to 425°C

📐 Design & Construction

The VINVAL 3PC ball valve is engineered with optimized features:

• Three-piece design: Easy maintenance and replacement of ball and seats
• Forged steel body: High precision, improved strength and sealing
• Precision-machined ball and seats: Minimize leakage
• Compatible with electric and pneumatic actuators

⭐ Key Advantages

✔️ 1. High pressure resistance and robust construction

The valve operates reliably in pressure ranges from Class 150 to Class 2500, suitable for oil & gas, hydraulic, and high-pressure systems.

✔️ 2. Excellent sealing performance

Precision machining ensures tight sealing between ball and seat, achieving extremely low leakage levels.

✔️ 3. Corrosion and wear resistance

Stainless steel materials F304L/F316L provide excellent resistance to acids, alkalis, chemicals, and seawater.

✔️ 4. Easy operation and low flow resistance

A quarter-turn (90°) operation allows quick opening/closing and reduces pressure loss, improving system efficiency.

✔️ 5. Compact and flexible design

Compact structure makes it suitable for installations in limited or complex spaces.

✔️ 6. Wide media compatibility

Suitable for various media such as gas, water, oil, steam, and chemicals, even under demanding conditions.

🏭 Applications

The VINVAL forged 3PC ball valve is widely used in:

• Oil & gas and petrochemical industries
• Chemical processing plants
• Water, steam, and compressed air systems
• Food and pharmaceutical industries (with stainless steel materials)
• High-pressure pipeline systems
