Temperature Regulator Valves

Temperature Regulator Valves

Price: Contact

  • Model:
  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Temperature Regulator

    OB-30, OB-30U, OB-31, OB-31U, OB-2000, OB-1, OB-1G, OB-2, OB-2G, OB-3, OB-3G, OB-4, OB-4G

    DOWNLOAD CATALOG

    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-30
    OB-30    		 15A -25A
    (1/2"-1")    		 Steam
    Water    		 1.7MPa Screwed Bronze

    For heating, small

    and compact



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-30U
    OB-30U    		 15A -25A
    (1/2"-1")    		 Steam
    Water    		 1.7MPa Screwed Bronze For heating, union joint



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-31
    OB-31    		 15A -25A
    (1/2"-1")    		 Water
    Refrigerant    		 1.7MPa Screwed Bronze

    For cooling, small

    and compact



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-31U
    OB-31U    		 15A -25A
    (1/2"-1")    		 Water
    Refrigerant    		 1.7MPa Screwed Bronze For cooling, union joint



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-2000
    OB-2000    		 15A -100A
    (1/2"-4")    		 Steam 2MPa Screwed
    JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 Ductile cast iron

    For heating,

    large capacity



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-1
    OB-1    		 15A -40A
    (1/2"-1-1/2")    		 Steam
    Water    		 0.7MPa Screwed Bronze For heating



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-1G
    OB-1G    		 15A -40A
    (1/2"-1-1/2")    		 Steam
    Water    		 0.7MPa Screwed Bronze

    For heating, external

    pressure bellows



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-2
    OB-2    		 15A -150A
    (1/2"-6")    		 Steam
    Water    		 0.7MPa JIS flange_JIS 10K Cast iron For heating, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-2G
    OB-2G    		 15A -125A
    (1/2"-5")    		 Steam
    Water    		 0.7MPa JIS flange_JIS 10K Cast iron

    For heating, external

    pressure bellows



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-3
    OB-3    		 15A -40A
    (1/2"-1-1/2")    		 Water
    Refrigerant    		 0.7MPa Screwed Bronze For cooling



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-3G
    OB-3G    		 15A -40A
    (1/2"-1-1/2")    		 Water
    Refrigerant    		 0.7MPa Screwed Bronze

    For cooling, external

    pressure bellows



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-4
    OB-4    		 15A -150A
    (1/2"-6")    		 Water
    Refrigerant    		 0.7MPa JIS flange_JIS 10K Cast iron For cooling, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    OB-4G
    OB-4G    		 15A -125A
    (1/2"-5")    		 Water
    Refrigerant    		 0.7MPa JIS flange_JIS 10K Cast iron

    For cooling, external

    pressure bellows
