Temperature Regulator Valves

OB-31U - Temperature Regulator Valves

Price: Contact

  • Model: OB-31U
  • DOWNLOAD CATALOG

  • Trademark: YOSHITAKE
  • Origin: Japan
  • Temperature Regulator

    OB-31U

    * Small and compact, but accurate control
    * PTFE/Stainless valve & seat enables long durability.

    Specifications

    Features For cooling, union joint
    Type External pressure bellows type
    Specifications Product type For cooling
    Nominal size 15A (1/2") - 25A (1")
    Application Water, refrigerant
    End connection JIS Rc screwed (union joint)
    Max. pressure 1.7 MPa
    Working temperature Max. 185 degree(C)
    Temperature regulating range 0-35 degree(C), 25-70 degree(C), 40-100 degree(C), 60-130 degree(C), 70-150 degree(C)
    Capillary length 2m
    Material Body Bronze
    Valve disc PTFE
    Thermal bulb Stainless steel

    Remarks

    * Standard capacity length is 2m. 3m or 5m options are available.


    Weights and Dimensions
    Size L (mm) H (mm) Weight (kg)
    15A(1/2) 75 318.5 2.7
    20A(3/4) 80 318.5 2.8
    25A(1) 90 318.5 3
