Electric Valve

VINVAL Motorized Actuator Ball Valve - Female Thread

Price: Contact

Model:

Female Thread Motorized Actuator Ball Valve

Two piece two way GB standard motorized ball valve, electric actuation. 316 stainless steel body, with a quarter turn 90 degree electric actuator. Torque range from 50Nm to 160Nm. Size optional: 1/2 inch, 3/4 inch, 1 inch, 1 1/4 inch, 1 1/2 inch and 2 inch. Available in DC-12V, 24V; AC 110V, 220V, 380V 50/60Hz. Widely used in water treatment, etc.

VINVAL is professional electric ball valve manufacturer over 25 years

Size Range: 1/4'' to 4''
Pressure Range: 0 to 1.6MPa
Material: Stainless Steel

Document

Catalog Download

Trademark: VINVAL

Origin: China

Order

Project details Download Catalogue Evaluate

Stainless steel Motorized Valve

Features:

The 2 piece ball size, large diameter, switch easy and convenient
Consistent product quality and reduction of defective rate
Reliable maintenance, sealing surface and sphere often closed state, not easy to be medium erosion
Significant cost reduction versus competitors
Excellent strength and toughness, easy installation
It can be applied to water, gas, steam, oil, nitric acid, acetic acid and other media
Cheaper and cost-efficient actuator valve for your business.

ON/OFF Type	Feedback: the active contact signal, passive contact signal, resistance, 4-20mA
Regulation Type	Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V
Field operation	The Field, Remote Control Switch Regulation and MODBUS, PROFIBUS Field Bus
Voltage Optional	AC110-240V 380V 50/60HZ: DC12V, DC24V, Special Voltage Can be Customized
Protection Class	IP65, Explosion Proof Construction Are Available: EX ll BT4

Body		Valve components
Size Range	DN08-DN100	Seating material	PTFE: -20℃~180℃ PPL: -20℃~150℃
Body Material	SS304, SS316, SS316L	Core Material	Stainless Steel
End Connection	Female Thread	Stem Material	Stainless Steel
Operating Pressure	PN1.6MPa	Applicable media	Control of water, Air, Gas, Oil, Liquid, Steam
Structure	Floating ball core	Applicable media	Control of water, Air, Gas, Oil, Liquid, Steam

● ON/OFF Type Electric Actuator: 90 degree rotation. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.

● Modulating Type Electric Actuator: Adjust open/close angle from 0 to 90 degree. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.

● Intelligent Type Electric Actuator: Adjust open/close angle from 0 to 90 degree. LED display screen to allow you check the open/close angle easier. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.

Series	5	10	16	30	60	125	250	400
Torque Output	50Nm	100Nm	160Nm	300Nm	600Nm	1250Nm	2500Nm	4000Nm
90° Cycle Time	20S	15/30S	15/30S	15/30S	30S	100S	100S	100S
Angle Of Rotation	0-90°	0-90°	0-90°	0-90°	0-90°	0-90°	0-90°	0-90°
Working Current	0.23A	0.35A	0.4A	0.45A	0.6A	1.03A	1.85A	2.7A
Drive Motor	50W	75W	80W	100W	130W	210W	285W	360W
Mounting Standard	ISO5211 direct mounting
Voltage Options	DC12V, DC24V, AC24V, AC110V, AC220V, AC380V
Input Signal	4-20mA, 1-5VDC, 0-10VDC
Output Signal	4-20mA, 1-5VDC, 0-10VDC
Protection Class	IP65 protection class
Ambient Temp	-20 to +60°C
Wiring Diagram	A: ON/OFF type with light indicator signal feedback
	B: ON/OFF type with passive contact signal feedback
	C: ON/OFF type with resisance potentiometer signal feedback
	D: ON/OFF type with resistance potentiometer and neutral posistion signal feedback
	E: Regulation type with servo control module
	F: DC24/DC12V direct ON/OFF type
	G: AC380V 3-phase power supply with passive signal feedback
	H: AC380V 3-phase power supply with resistance potentiometer and neutral posistion signal feedback
