Electric Actuator 3PC Ball Valve - VINVAL

Price: Contact

Model:

Electric Actuator 3PC Ball Valve

VINVAL electric ball valve, standard on/off control, 4-20mA or 0-10VDC modulating control is available, stainless steel body construction, optional WCB, 220VAC standard voltage, minimum 1/4 inch female thread connection, default PTFE seat, resistant to almost all fluids. Suitable for higher operating pressures and temperatures. Size range available in 1/2 inch, 3/4 inch, 1 inch, 1 1/4 inch, 1 1/2 inch, 2 inch, 2.5 inch, 3 inch and 4 inch. Voltage optional: 12V, 24V DC; 24V, 110V, 220V, 380V AC.

Welcome to contact us to get the most competitive electric ball valve price!

Size Range: 1/4" to 4"
Pressure Range: 1.6 to 6.4MPa
Material: WCB, Stainless Steel

Catalog Download

Catalog Download

Trademark: VINVAL

Origin: China

Order

Project details Download Catalogue Evaluate

Electric 3Pieces Stainless Steel Ball Valve

● Features: Compact Design, Eco-friendly, Easy Installation, etc
● Torque: 50N.m or 4000N.m
● Rotation: Quarter-turn
● Actuator Type: ON OFF Type, Regulating Type and Intelligent Type
● Material: Stainless Steel
● Connection: 3PC Thread, Tri Clamp, Flange and Welding
● Suitable for water, oil, air, etc. Widely used in HVAC, irrigation, water treatment, etc.

Technical Parameter of Valve Body:

Body Material	Stainless Steel 304/316/316L	Working Pressure	10 / 16 / 20 / 64 bar
Temperature Of Media	-30~180℃ (-22℉~356℉)	Suitable Media	Water, Air, Oil, Gas, etc
Structure	Straight Through Flow Path	Voltage	DC-12V, 24V; AC-24V, 110V, 220V, 380V
Port size range	DN08-DN100	Voltage Tolerance	±10%
Actuator Type	ON OFF Type, Modulating Type, Intelligent Type, Explosion-proof Type and Multi-turn Type	Port Thread	Threaded/Flanged/Welding/Tri-clamp

Technical Parameter of Actuators:

ON/OFF Type	Feedback: the active contact signal, passive contact signal, resistant, 4-20mA
Regulation Type	Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V
Field Operation	The field, remote control switch regulation and MODBUS, PROFIBUS field bus
Voltage optional	AC 110-240V 380V 50/60Hz; DC12V, DC24V, Special voltage can be customized
Protection Class	IP65

Model	05	10	16	30	60	125	250	400
Torque Output	50Nm	100Nm	160Nm	300Nm	600Nm	1250Nm	2500Nm	4000Nm

ON/OFF Type Electric Actuator: 90 degree rotation. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.
Modulating Type Electric Actuator: Adjust open/close angle from 0 to 90 degree. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.
Intelligent Type Electric Actuator: Adjust open/close angle from 0 to 90 degree. LED display screen to allow you check the open/close angle easier. AC/DC power supply, signal control and manual override. High torque up to 4000Nm.
