Steam Trap/Air Trap

TSF-10 - Float Steam Trap

Price: Contact

Model: TSF-10

Trademark: YOSHITAKE

Origin: Japan

Order

Project details Download Catalogue Evaluate

Float Steam Trap

TSF-10

* Incorporated thermostatic air vent discharges air smoothly and shortens warming-up time.
* Flow direction can be switched easily without disassembly.
* Since the main parts are installed on the cover, parts replacement can be easily.

Specifications

Features		Adjustable flow direction
Type		Float type steam trap
Specifications	Product type	Steam Trap_Float
	Nominal size	15A (1/2") - 25A (1")
	Application	Steam condensate
	End connection	JIS Rc or NPT screwed
	Max. pressure	2.1 MPa
	Working pressure	0.01 - 2.1 MPa (depends on orifice)
	Working temperature	Max. 220 degree(C)
Material	Body	Ductile cast iron
	Valve and valve seat	Stainless steel
	Float	Stainless steel
