Steam Trap/Air Trap

Steam Trap/Air Trap

Price: Contact

  • Model:

    •

  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Steam Trap/Air Trap

    TSF-10, TSF-10F, TSF-11, TSF-11F, TSF-8, TSF-10S, TSF-10SF, TSF-11S, TSF-11SF, TSF-12, TSF-13, TSF-13F, TF-1, TF-2, TB-20, TB-20F, TB-5, TD-10NA, TD-30NA, TSD-7, TSD-7F, TSD-42, TSD-42F, TSD-46, TS-7, TS-8, TSF-8AT, TSF-11AT

    DOWNLOAD CATALOG

    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-10
    TSF-10    		 15A -25A
    (1/2"-1")    		 Steam
    Steam condensate    		 2.1MPa Screwed Ductile cast iron Adjustable flow direction



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-10F
    TSF-10F    		 15A -25A
    (1/2"-1")    		 Steam condensate 2.1MPa JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN16
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 Ductile cast iron

    Adjustable flow

    direction, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-11
    TSF-11    		 25A -50A
    (1"-2")    		 Steam condensate 2.1MPa Screwed Ductile cast iron Adjustable flow direction



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-11F
    TSF-11F    		 25A -50A
    (1"-2")    		 Steam condensate 2.1MPa JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN16
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 Ductile cast iron

    Adjustable flow

    direction, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-8
    TSF-8    		 15A -25A
    (1/2"-1")    		 Air,non-dangerous fluids 2.1MPa Screwed Ductile cast iron

    Ductile cast iron,

    screwed



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-10S
    TSF-10S    		 15A -25A
    (1/2"-1")    		 Steam condensate 2.1MPa Screwed Stainless steel

    Adjustable flow direction,

    all stainless steel



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-10SF
    TSF-10SF    		 15A -25A
    (1/2"-1")    		 Steam condensate 2.1MPa JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN16
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 Stainless steel Adjustable flow direction, stainless steel, flanged

    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-11S
    TSF-11S    		 25A -50A
    (1"-2")    		 Steam condensate 2.1MPa Screwed Stainless steel Adjustable flow direction, stainless steel



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-11SF
    TSF-11SF    		 25A -50A
    (1"-2")    		 Steam condensate 2.1MPa JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN16
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 Stainless steel

    Adjustable flow direction,

    stainless steel, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-12
    TSF-12    		 40A -50A
    (1-1/2"-2")    		 Steam condensate 1.7MPa Screwed Ductile cast iron

    Ductile cast iron,

    screwed



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-13
    TSF-13    		 40A -50A
    (1-1/2"-2")    		 Steam condensate 1.6MPa Screwed Ductile cast iron Large capacity, screwed



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-13F
    TSF-13F    		 40A -50A
    (1-1/2"-2")    		 Steam condensate 1.6MPa JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN16
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 Ductile cast iron

    Large capacity,

    flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TF-1
    TF-1    		 15A -50A
    (1/2"-2")    		 Steam condensate 0.3MPa JIS flange_JIS 10K Ductile cast iron Maximum size 80A



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TF-2
    TF-2    		 15A -50A
    (1/2"-2")    		 Steam condensate 0.7MPa Screwed Ductile cast iron Max. 0.7MPa, screwed

    Model Nominal size Application Max. pressure End connection Body Material Feature
    TB-20
    TB-20    		 15A -25A
    (1/2"-1")    		 Steam condensate 1.6MPa Screwed Ductile cast iron

    Bucket, 1.6 MPa,

    screwed



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TB-20F
    TB-20F    		 15A -25A
    (1/2"-1")    		 Steam condensate 1.6MPa JIS flange_JIS 10K
    JIS flange_JIS 20K    		 Ductile cast iron

    Bucket, 1.6 MPa,

    flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TB-5
    TB-5    		 15A -50A
    (1/2"-2")    		 Steam condensate 1MPa JIS flange_JIS 10K Ductile cast iron Bucket, 1.0 MPa, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TD-10NA
    TD-10NA    		 15A -25A
    (1/2"-1")    		 Steam condensate 2MPa Screwed Ductile cast iron

    Disc, screwed,

    2.0MPa



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TD-30NA
    TD-30NA    		 15A -25A
    (1/2"-1")    		 Steam condensate 2MPa JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN16
    EN flangeEN PN25    		 Ductile cast iron

    Disc, flanged,

    2.0MPa



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSD-7
    TSD-7    		 15A -25A
    (1/2"-1")    		 Steam condensate 1MPa Screwed Ductile cast iron Disc, built-in bypass



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSD-7F
    TSD-7F    		 15A -25A
    (1/2"-1")    		 Steam condensate 1MPa JIS flange_JIS 10K Ductile cast iron Disc, built-in bypass, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSD-42
    TSD-42    		 10A -25A
    (3/8"-1")    		 Steam condensate 4.2MPa Screwed SCS2A stainless steel

    Disc, stainless steel,

    4.2MPa



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSD-42F
    TSD-42F    		 15A -25A
    (1/2"-1")    		 Steam condensate 4.2MPa JIS flange_JIS 10K
    JIS flange_JIS 20K
    JIS flange_JIS 30K
    JIS flange_JIS 40K
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 SCS2A stainless steel

    Disc, stainless steel,

    4.2MPa, flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSD-46
    TSD-46    		 15A -25A
    (1/2"-1")    		 Steam condensate 4.6MPa Socket weld Forged stainless steel Disc, stainless steel, 4.6MPa, socket weld



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TS-7
    TS-7    		 15A -25A
    (1/2"-1")    		 Steam condensate 1MPa Screwed Ductile cast iron Bellows, built-in bypass



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TS-8
    TS-8    		 15A -25A
    (1/2"-1")    		 Steam condensate 1MPa JIS flange_JIS 10K Ductile cast iron

    Bellows, built-in bypass,

    flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-8AT
    TSF-8AT    		 15A -25A
    (1/2"-1")    		 Air,non-dangerous fluids 2.1MPa Screwed Ductile cast iron Air trap, screwed



    Model Nominal size Application Max. pressure End connection Body Material Feature
    TSF-11AT
    TSF-11AT    		 32A -50A
    (1-1/4"-2")    		 Air,non-dangerous fluids 2.1MPa Screwed FCD450 Air trap, screwed
