68 DEHM-MR

Hydraulically Actuated, Manual Reset Deluge Valve

Hydraulically controlled deluge/pre-action valve, actuated by the pipeline pressure. The valve is closed in its normal, set position and opens when the hydraulic pressure drops in a pressurized pilot line, limited to 7m above the valve (for higher pilot lines, see DEHRV-MR model sheet). The valve must be manually reset following automatic actuation. An emergency manual release valve is fitted as standard.

FEATURES & BENEFITS

• High pressure (PN25/375psi), high flow deluge systems
• Automatic or local manual emergency actuation
• Hazardous, flammable & explosion classified area fire suppression
• Superior design featuring exceptionally low pressure losses at high flow rates
• Low lifelong maintenance costs due to straightforward design
• Applicable for fresh or brackish water, seawater & foam
• Out of box fully assembled & tested valves
• Factory trimmed for vertical & horizontal installations without modification
• Extensive valve & trim materials selection and corrosion protection coating
