115-1DV

Electrically Actuated Deluge Valve

Electrically controlled deluge valve, actuated by the pipeline pressure. The valve is closed in its normal, set position and opens when a 3-way solenoid valve is energized. It closes drip tight when the solenoid valve is de-energized. An emergency manual release valve is fitted as standard.

FEATURES & BENEFITS

• Simple design utilizes a 3-way solenoid valve that directly operates the main valve
• Opens quickly when the solenoid valve is activated (specify energize-to-open or energize-to-close)
• Manual override to open the valve regardless of solenoid valve position
• Visual indicator for indication of valve position
• Large supply drain port to drain inlet side piping – globe only
• Solenoid operated main valve
• No adjustments necessary
• Factory tested
• Standard sizes 1.25” through 4”
• ANSI Flanged Class #150 or Class #300
• Wide range of materials available
• Options available include opening and/or closing speed controls, limit switch assembly and pressure gauge(s)
