YSS-511F Type - Air Separator

This is used in cooling and heating systems to continuously remove air contained in fluid. All air generated by systems can be automatically removed, thanks to its superb air discharge capability. Air can be discharged even at the micro-bubble level.

Features

• Used in cooling & heating systems to continuously remove air contained in fluid.
• All air generated by systems can be automatically removed & discharged even at Microbubble level.
• Air-free water enables optimal operation & prevents noise, corrosion, partial overheating, and mechanical damage.
• Complete thermal insulation effects are achieved in cold and hot water systems with lagging material

Specification:

• Type: YSS-511F
• Size 50~150A
• Applicable pressure: 1.0MPa
• Applicable fluid : Cold/hot water
• Fluid temperature : 120℃ below
• End connection: KS JIS 10K RF FLANGE
• Materials
  • Body: Epoxy-coated steel
  • Internal parts : STS
  • Seal : EPDM
• Waterway: PT 1”

▶ Dimensions are subject to change without prior notice for product quality improvements (performance improvements).
▶ Made-to-orders are available for 200A or larger.
