YAC-3M Type - Automatic Air Vent Valve

As an air vent valve for liquid, it automatically discharges remaining air from pipelines and air from sealed tanks, thereby allowing for smooth flow of fluid.

Features

• Low pressure also operates smoothly.
• Disk designs are designed to be free and smooth and sensitive.
• Made for easy repair and inspection.
• Stilleball installation prevents air ingress into the air.


Specification:

• Type: YAC-3M
• Size: 15(½”)
• Applicable fluid: Cold / hot water
• Applicable pressure: Maximum 1.0MPa
• Fluid temperature: 5~80°C
• End connection: KS PTS CREW(Female)
• Materials
  • Body: CAC303
  • Disc, seat: EPDM, STS
• Hydraulic test pressure: 1.5MPa

▶ Install a strainer (40 MESH or more) on the leaflet during installation of the valve.
