YSS-100S/F Type Drain Separator

TThis product ensures that there is no pressure loss within the pipeline, and is designed in a way that allows an effective water separation function even when there are flow velocity changes. It can thus be used for steam pipelines as well as compressed air pipelines.

Features

• Protects process facilities & extends life span by preventing damage caused by Water Hammer in steam system.
• Shield board designed condensate which is separated steam’s flow efficiently gathered at discharge point.
• Almost no pressure loss within pipeline, efficiently separates condensate even in extensive flow velocity changes.

Specification:

• Type: YSS-100S
• Applicable fluid : Steam
• Applicable pressure : Maximum 2.0MPa
• Fluid temperature: 220°C below
• End connection: KS PT SCREW
• Materials
  • Body SPPS
  • Screen STS
• Hydraulic test pressure 3.0MPa

▶ In terms of the end connection, the PT, NPT, KS, and ANSI standards can be applied.
▶ Creating an order for 10K
