YKY-11 Type - Y-Strainer

Features

• Approved by the Korean Industrial Standard (KS B1538).
• Extremely fine meshes screen can filter all foreign substances.
• Designed to ensure easy disassembly & assembly, and has a drain plug installed

Specification:

• Type :YKY-11
• Applicable fluid: Steam
• Applicable pressure: Maximum 1.0MPa
• Fluid temperature: 220°C below
• End connection : KS PT SCREW
• Materials
  • Body : GC200
  • Cover : C3771
  • Screen : STS Wire Net
• Hydraulic test pressure 1.5MPa

*** It is recommended to choose the number of meshes when buying a filter: (the most important point when choosing a filter): For liquids, it is recommended to use a filter from 20-40 Mesh depending on the viscosity of each fluid. With steam, it is recommended to use an 80 Mesh filter according to the standards of Japan and Korea. With Air & Vapor, the filter is often used more than 100 Mesh depending on the filtration needs of each customer. All are made to order when ordered.
