Hammerless Check Valve

YHL-200 Type - Hammerless Check Valve Flanged JIS20K

Price: 8,824,000 d

  • Model: YHL-200
  • Trademark: SAMYANG
  • Origin: Korea
  • Size: DN50
  • YHL-200 Type - Hammerless Check Valve Flanged JIS20K

    This product is used to prevent fluid from flowing backwards into a hammerless check valve pump outlet. It prevents water hammers, protects pump pipelines, and also functions as a bypass valve.

    Features

    • Water Hammer free.
      • Prevent Water Hammer :The valve closes when fluid inside the pipeline becomes a speed of stoppage, based on precise movements of the spring & built-in buffer (a part inside the valve that resembles an umbrella playing an essential role in preventing Water Hammer).
    • Suitable for pumps, pipelines protection & environmental preservation :Heavy noise & pressure loss, this is the most ideal valve for high-rise apartment buildings and other types of high-rise buildings, underground shopping malls, public office buildings, and other public buildings with little Water Hammer shock.
    • Breakdown-free simple structure.
    • One-year warranty if there is malfunction.
    • Bypass valve function.
    • Withdraw water inside pipeline on pump outlet side as bypass valve & replenishes guiding water when vacuum establishes on pump inlet side.

    Specification:

    • Type: YHL-200
    • Maximum running pressure: Maximum 2.0MPa
    • Applicable fluid: Water
    • Fluid temperature: 5~80℃
    • Leakage allowance: ANSI b16.104 Class V
    • End connection: KS 20K RF FLANGE
    • Materials
      • Body: GCD450
      • Disc: NBR, CAC406
      • Seat: CAC 406
    • Hydraulic test pressure: 3.0MPa

    ▶ Manufacturer's order for 2.0 MPa.
    ▶ Produce SCH2 Orders
