YFV-1 Type - Foot Valve Flanged JIS10K

When installed on the pump inlet side of an underground water tank, this product is suitable for preventing the backward flow of fluid.

Specification:

• Applicable fluid: Water
• Maximum running pressure: Maximum 1.0MPa
• Fluid temperature: 80℃ below
• Leakage allowance: ANSI b16.104 class V
• End connection: KS 10K RF FLANGE
• Materials
  • Body: GC200
  • Disc, seat: NBR, CAC406
  • Screen: STS
• Hydraulic test pressure: 1.5MPa
