YAWEL-1 Type Level Control Valve

The type YAWEL-1 is a largecapacity level control valve that supplies water by opening when the water level inside a water tank goes down to the level at which water supply is commenced. The valve closes when the water level rises to the level at which water supply is stopped. The valve thus features an outstanding performance in controlling the water level.

Features

• Automatically opened & closed, without external power supply even large-diameter.
• No leakage with special rubber diaphragm & disc.
• Attached speed control valve (needle valve) can adjust main valve’s opening & closing speed.
• Ensure easy repair & inspections structure.

Specification:

• Type: YAWEL-1
• Applicable fluid : Fresh water, industrial water, agricultural water
• Function: On and off operation by a pilot solenoid valve
• Minimum differential pressure in the inlet and outlet side of the valve : Maximum 10 kgf/cm2g
• Fluid temperature : 5~80°C
• Function : On - off operation by solenoid electronic valve
• Solenoid Valve
  • Standard : 200~350A : PT1”
  • Power:  AC220V, 50/60Hz
• End connection: KS 10K RF FLANGE
• Materials
  • Body: GC200
  • Disc, seat : NBR, CAC406
  • Diaphragm : NBR
• Hydraulic test pressure 1.5MPa

▶ Install a strainer (40 MESH or more) on the leaflet during installation of the valve.
