YAW-3S Level Control Valve

The type YAW-3S and 3F water level control valves were developed for the exclusive purpose of controlling the water level of a wide array of water tanks. They are optimal water level control valves that have a simple structure and are small sized and lightweight, thereby ensuring easy handling and installation.

Features

• Embedded strainer prevents various foreign substances into the pipeline.
• No external pipeline, kept warm easily & no concerns of freezing damage.
• Large capacity make suitable for apartment water & elevated tanks.
• EM mark acquired

Specification:

• Type YAW-3S
• Size 32A~40A
• Applicable pressure Maximum 1.0MPa
• Minimum differential pressure in the inlet and outlet side of the valve : 0.034MPa
• Fluid temperature: 5~80℃
• Function : On and off operation by a pilot solenoid valve
• Solenoid valve: AC220V, 50/60HZ
• Applicable fluid : Drinking water, fresh water, industrial water, agricultural water
• End connection : KS PT SCREW
• Materials
  • Body: GC200
  • Disc, seat: NBR, CAC406
• Hydraulic test pressure: 1.5MPa

▶ Install a strainer (40 MESH or more) on the leaflet during installation of the valve
