F316 High Pressure Hard Sealing Forged Globe Valve

Applicable Standards:

• Gate valve Design standard: API602
• Steel Valves Design standard: ASME B16.34
• Face to face standard: ASME B16.10/MFG’S STANDARD
• Socket Welded standard: ASME B16.11
•  Screw Threaded standard: AEME B1.20.1/BS 21
• End Flanges standard: ASME B16.5
• Butt welding ends standard: ASME B36.10M
• Inspection and test standard: API 598

Material: Forged Steel (F316)
Size Range: 1/2"~2"
Pressure Rating: ASME CL, 150, 300, 600, 900, 1500, 2500
Temperature Range:  -29°C~425°C
Design Description: Butt Welded Ends, Flanged Ends, Socket Weld Ends, Pup End,...
