Waste Heat Recovery

Steam Condensing Heat Exchanger - SR Series

Price: Contact

Model: SR-3 & SR-8

Trademark: TLV

Origin: Japan

Order

Project details Download Catalogue Evaluate

Steam Condensing Heat Exchanger

SR Series

Eliminate “steam clouds” and recover heat energy as hot water

Hot water generated by SR series is suitable for cleaning/preheating water for production processes, bottle washing and other post-production cleaning applications. Unique structure that does not apply pressure makes recovery of atmospheric pressure steam possible.

Flash Steam and Waste Water Heat Exchangers Pamphlet (806 KB)

Benefits and Features

Energy savings via heat energy (waste steam) use

The heat exchange capacity is comparable to that of a sealed heat exchanger, enabling effective use of heat that would otherwise be discarded.

Large Degree of Freedom for Installation

The product can be easily introduced as it is an open-to atmosphere system free from the restrictions and regulations governing pressure vessels.

Application Areas

Heat recovery from steam in processes to where pressure cannot be applied (Waste steam heat recovery from steamers, set machines, etc.)
Treatment of re-evaporated steam from supply water/condensate tanks
Improving work environment where steam clouds are generated around the plant

SR-3/SR-8 applications - Effective use of waste steam

Product Details

Model	Photo	Steam Inlet	Body/Heat Transfer Coil Material	PMO (MPaG)		TMO (°C)	Max. Steam Flow Rate (kg/h)	Catalogue
Model	Photo	Steam Inlet	Body/Heat Transfer Coil Material	Body (Shell side)	Coil (Tube side)	TMO (°C)	Max. Steam Flow Rate (kg/h)	Catalogue
SR-3		Flanged	Stainless (SUS304)	0	1.0	100	300	Specifications
SR-8		Flanged	Stainless (SUS304)	0	1.0	100	800	Specifications
