Strainer

SY-5, SY-40, SY-40H, SY-40EN, SY-40C-N, SY-9, SY-17, SY-37, SY-6, SY-6-N, SY-24, SY-24-N, SY-2, SY-8, SY-38, SY-20-10, SY-20-20, SY-10-30, SY-13, SU-20, SU-20S, SU-20C, SU-20H,
SU-10, SU-10S, SU-50H, SU-50S, ST-10, SU-6, SU-55F, SW-10, SW-10S, ST-1-10,

DOWNLOAD CATALOG

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-5	10A -50A (3/8"-2")	Steam Water Oil Air,non-dangerous fluids	2MPa	Screwed	Ductile cast iron	Ductile cast iron, Max. 2.0MPa

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-40	15A -300A (1/2"-12")	Steam Water Oil Air,non-dangerous fluids	1MPa	JIS flange_JIS 10K Socket weld	Ductile cast iron	Ductile cast iron, flanged

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-40H	15A -150A (1/2"-6")	Steam Water Air,non-dangerous fluids	2MPa	JIS flange_JIS 20K ASME flange_ASME Class 300	Ductile cast iron	Ductile cast iron, flanged, Max. 2.0MPa

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-40EN	15A -150A (1/2"-6")	Steam Water Oil Air,non-dangerous fluids	2MPa	EN flangeEN PN16 EN flangeEN PN25	Ductile cast iron	Ductile cast iron, EN flange

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-40C-N	15A -150A (1/2"-6")	Water Air,non-dangerous fluids	1MPa	JIS flange_JIS 10K	Ductile cast iron	Nylon coating, JWWA approved

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-9	15A -50A (1/2"-2")	Water Air,non-dangerous fluids	1MPa	Screwed	Ductile cast iron	Easy plug type

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-17	15A -50A (1/2"-2")	Steam Water Oil Air,non-dangerous fluids	2MPa	Screwed	Stainless steel	Stainless steel

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-37	15A -50A (1/2"-2")	Steam Water Oil Air,non-dangerous fluids	2MPa	Screwed	Stainless steel	Stainless steel, fine mesh

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-6	15A -50A (1/2"-2")	Steam Water Oil Air,non-dangerous fluids	1.3MPa	Screwed	Bronze	Bronze, screwed

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-6-N	15A -50A (1/2"-2")	Water	1.3MPa	Screwed	Bronze	Bronze (NPb treated), JWWA approved

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-24	15A -50A (1/2"-2")	Water	1.6MPa	Screwed	Bronze	Bronze, Rc x R screwed

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-24-N	15A -50A (1/2"-2")	Water	1.6MPa	Screwed	Bronze	Bronze (NPb-treated), Rc x R screwed, JWWA approved

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-2	200A (8")	Steam Water Air,non-dangerous fluids	2MPa	JIS flange_JIS 20K	Ductile cast iron	Ductile cast iron, Max. 2.0MPa, 200A

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-8	15A -150A (1/2"-6")	Steam Water Oil Air,non-dangerous fluids	MPa	JIS flange_JIS 10K	Stainless steel	Stainress steel, flanged

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-38	15A -150A (1/2"-6")	Steam Water Oil Air,non-dangerous fluids	MPa	JIS flange_JIS 10K	Stainless steel	Stainress steel, flanged, fine mesh

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-20-10	15A -150A (1/2"-6")	Steam Water Oil Air,non-dangerous fluids	1MPa	JIS flange_JIS 10K	Cast carbon steel	Carbon steel, 10K flanged

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-20-20	15A -150A (1/2"-6")	Steam Water Oil Air,non-dangerous fluids	2MPa	JIS flange_JIS 20K	Cast carbon steel	Carbon steel, 20K flanged

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-10-30	15A -250A (1/2"-10")	Steam Water Oil Air,non-dangerous fluids	3MPa	JIS flange_JIS 30K	Cast carbon steel	Carbon steel, 30K flanged

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SY-13	200A -350A and larger (8"-14")	Steam Water Air,non-dangerous fluids	1MPa	JIS flange_JIS 10K	Carbon steel	Carbon steel, large size

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-20	20A -150A (3/4"-6")	Water Oil	1MPa	JIS flange_JIS 10K	Ductile cast iron	Ductile cast iron

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-20S	20A -125A (3/4"-5")	Water Oil	1MPa	JIS flange_JIS 10K	Ductile cast iron	Easy maintenance

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-20C	20A -150A (3/4"-6")	Water Oil	1MPa	JIS flange_JIS 10K	Ductile cast iron	Nylon coating

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-20H	200A (8")	Water Oil	2MPa	JIS flange_JIS 10K JIS flange_JIS 20K	Ductile cast iron	Ductile cast iron, with anchor

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-10	20A -150A (3/4"-6")	Water Oil	1MPa	JIS flange_JIS 10K	Stainless steel	Stainless steel

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-10S	20A -150A (3/4"-6")	Water Oil	1MPa	JIS flange_JIS 10K	Stainless steel	Stainless steel, easy maintenance

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-50H	50A -150A (2"-6")	Water Oil	MPa	JIS flange_JIS 20K	Ductile cast iron	Max. 2.0 MPa

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-50S	50A -150A (2"-6")	Water Oil	1MPa	JIS flange_JIS 10K EN flangeEN PN16	Ductile cast iron	Easy maintenance

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
ST-10	125A -250A (5"-10")	Water Oil	1MPa	JIS flange_JIS 10K	Ductile cast iron	Straight type, ductile cast iron

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-6	200A -350A and larger (8"-14")	Water Oil	MPa	JIS flange_JIS 10K	Carbon steel	Carbon steel, large size

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SU-55F	15A (1/2")	Water	1.2MPa	Screwed	Bronze	Screwed, bronze

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SW-10	20A -100A (3/4"-4")	Water Oil	1MPa	JIS flange_JIS 10K	Ductile cast iron or stainless steel	Duplex type

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
SW-10S	20A -100A (3/4"-4")	Water Oil	1MPa	JIS flange_JIS 10K	Ductile cast iron or stainless steel	Duplex type, easy maintenance

---

Model	Nominal size	Application	Max. pressure	End connection	Body Material	Feature
ST-1-10	25A -300A (1"-12")	Steam Water Air,non-dangerous fluids	1MPa	JIS flange_JIS 10K	Stainless steel	Temporary strainer
