Manual Valves/Strainer/Sight Glass

Sight Glass/Flow Meter

Price: Contact

  • Model:
  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Sight Glass/Flow Meter

    SL-1S, SL-1F, SF-1S, SF-1F, SB-1S, SB-1F, 150L-F, 150F-F, 150L-13S, 150L-13F, 150F-13S, 150F-13S, F150F-13F, 150F-13F, 400, FS-I-Z, FSJ-B, FS-B, FS-II-P, FS-M, FS-IV

    DOWNLOAD CATALOG


    Model Nominal size Application Max. pressure End connection Body Material Feature
    SL-1S
    SL-1S    		 15A -50A
    (1/2"-2")    		 Water
    Oil    		 1MPa Screwed Ductile cast iron

    Plain type, ductile cast iron,

    screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SL-1F
    SL-1F    		 15A -50A
    (1/2"-2")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron

    Plain type, ductile cast iron,

    flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SF-1S
    SF-1S    		 15A -50A
    (1/2"-2")    		 Water
    Oil    		 1MPa Screwed Ductile cast iron

    Flap type, ductile iron,

    screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SF-1F
    SF-1F    		 15A -50A
    (1/2"-2")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron

    Flap type, ductile cast iron,

    flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SB-1S
    SB-1S    		 15A -50A
    (1/2"-2")    		 Water 1MPa Screwed Ductile cast iron

    Ball type, ductile cast iron,

    screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SB-1F
    SB-1F    		 15A -50A
    (1/2"-2")    		 Water 1MPa JIS flange_JIS 10K Ductile cast iron

    Ball type, ductile cast iron,

    flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    150L-F
    150L-F    		 65A -150A
    (2-1/2"-6")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron

    Plain type, ductile cast iron,

    large size
    Model Nominal size Application Max. pressure End connection Body Material Feature
    150F-F
    150F-F    		 65A -150A
    (2-1/2"-6")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron

    Flap type, ductile cast iron,

    large size
    Model Nominal size Application Max. pressure End connection Body Material Feature
    150L-13S
    150L-13S    		 15A -50A
    (1/2"-2")    		 Water
    Oil    		 1MPa Screwed Stainless steel

    Plain type, stainless steel,

    screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    150L-13F
    150L-13F    		 15A -100A
    (1/2"-4")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Stainless steel

    Plain type, stainless steel,

    screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    150F-13S
    150F-13S    		 15A -50A
    (1/2"-2")    		 Water
    Oil    		 MPa Screwed Stainless steel

    Flap type, stainless steel,

    screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    150F-13F
    150F-13F    		 15A -100A
    (1/2"-4")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Stainless steel

    Flap type, stainless steel,

    flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    400
    400    		 10A -25A
    (3/8"-1")    		 Water 0.7MPa Screwed Bronze Spinner type, bronze
    Model Nominal size Application Max. pressure End connection Body Material Feature
    FS-I-Z
    FS-I-Z    		 10A -50A
    (3/8"-2")    		 Water
    Oil    		 0.7MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Kawaki flow sight,

    plain type
    Model Nominal size Application Max. pressure End connection Body Material Feature
    FSJ-B
    FSJ-B    		 10A -25A
    (3/8"-1")    		 Water 0.7MPa Screwed Stainless steel

    Kawaki flow sight,

    ball type,

    stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    FS-B
    FS-B    		 10A -80A
    (3/8"-3")    		 Water 0.7MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Kawaki flow sight,

    ball type
    Model Nominal size Application Max. pressure End connection Body Material Feature
    FS-II-P
    FS-II-P    		 10A -150A
    (3/8"-6")    		 Water
    Oil    		 0.7MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Kawaki flow sight,

    flap type
    Model Nominal size Application Max. pressure End connection Body Material Feature
    FS-M
    FS-M    		 10A -150A
    (3/8"-6")    		 Water
    Oil    		 0.7MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Kawaki flow sight,

    magnet type
    Model Nominal size Application Max. pressure End connection Body Material Feature
    FS-IV
    FS-IV    		 10A -150A
    (3/8"-6")    		 Water
    Oil    		 0.7MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Kawaki flow sight,

    flap type
