Expansion Joint/Ball Joint/Flexible Joint
Expansion Joint/Ball Joint/Flexible Joint
Price: Contact
Expansion Joint/Ball Joint/Flexible Joint
EB-1J, EB-2J, EB-11, EB-12, ES-10-100, ES-10-200, BJ-1, YBF-1E, YBF-2E
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 EB-1J |
20A -250A (3/4"-10") |
Steam Water Oil Air,non-dangerous fluids |
1MPa | JIS flange_JIS 10K | Stainless steel | Bellows type, Single, 1.0MPa |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 EB-2J |
20A -250A (3/4"-10") |
Steam Water Oil Air,non-dangerous fluids |
1MPa | JIS flange_JIS 10K | Stainless steel | Bellows type, Double, 1.0MPa |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 EB-11 |
20A -250A (3/4"-10") |
Steam Water Oil Air,non-dangerous fluids |
2MPa | JIS flange_JIS 20K | Stainless steel | Bellows type, Single, 2.0MPa |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 EB-12 |
20A -250A (3/4"-10") |
Steam Water Oil Air,non-dangerous fluids |
2MPa | JIS flange_JIS 20K | Stainless steel | Bellows type, Double, 2.0MPa |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 ES-10-100 |
25A -200A (1"-8") |
Steam Water Oil Air,non-dangerous fluids |
1MPa | JIS flange_JIS 10K | Ductile cast iron or Cast iron | Sleeve type, 100mm |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 ES-10-200 |
25A -200A (1"-8") |
Steam Water Oil Air,non-dangerous fluids |
1MPa | JIS flange_JIS 10K | Carbon steel/Ductile cast iron | Sleeve type, 200mm |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 BJ-1 |
50A -250A (2"-10") |
Steam Water Oil Air,non-dangerous fluids |
1MPa | JIS flange_JIS 10K | Cast carbon steel | Ball joint, flanged, carbon steel |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 YBF-1E |
15A -50A (1/2"-2") |
Steam Water Oil Air,non-dangerous fluids |
1MPa | Screwed | Stainless steel | Screwed |
| Model | Nominal size | Application | Max. pressure | End connection | Body Material | Feature |
|---|---|---|---|---|---|---|
 YBF-2E |
15A -250A (1/2"-10") |
Steam Water Oil Air,non-dangerous fluids |
1MPa | JIS flange_JIS 10K | Stainless steel | Flanged |
