Expansion Joint/Ball Joint/Flexible Joint

EB-2J - Expansion Joint

Price: Contact

  • Model: EB-2J
  •

  • Trademark: YOSHITAKE
  • Origin: Japan
  • Expansion Joint

    EB-2J

    * Stainless steel wetted parts
    * With outer pipe and inner pipe

    Specifications

    Features Bellows type, Double, 1.0MPa
    Specifications Product type Expansion Joint_Bellows
    Nominal size 20A (3/4") - 250A (10")
    Application Steam, air, water, oil, other non-dangerous fluids
    End connection JIS 10K FF flanged
    Max. pressure 1 MPa
    Working temperature Max. 220 degree(C)
    Max. axial extension 70mm (Expansion 20mm, compression 50mm)
    Material Body Stainless steel
    Outer pipe Carbon steel (*)
    Bellows and inner pipe Stainless steel
