GAMBIT Gasket

Gambit Compressed Non-Asbestos Sheets & Gasket Model: AF-MF®

Price: Contact

  • Model: AF-MF®

    • Gambit Compressed Non-Asbestos Sheets & Gasket

    Model: AF-MF®



  • Trademark: WOOJUGASPACK
  • Origin: Korea
    • Project details Download Catalogue Evaluate

    Material

    • Bio-soluble mineral fibers, KevlarⓇ fibers, + NBR binder

    Characteristic

    • High-parameter, oil-resistant gasket sheet, thank to bio-soluble mineral fibers has a high thermal resistance, especially when working with steam.

    Specifications

    Maximum Working Conditions
    Peak Temperature ℃ 450
    Temperature Under Continuous Operation ℃ 350
    Temperature Under Continuous Operation With Steam ℃ 280
    Pressure MPa 12
    Physical and Chemical Properties
    Density (±5%) g/cm3 2.0 DIN 28090 - 2
    Transverse Tensile Strength (min.) MPa 9 DIN 52910
    Compressibility (Typical Value) % 10 ASTM F36
    Elastic Recovery (min.) % 55 ASTM F36
    Residual Stress 50MPa/16h/300℃ (min.) MPa 29 DIN 52913
    Residual Stress 50MPa/16h/175℃ (min.) MPa 35 DIN 52913
    Increase In Thickness
    Oil IRM 903 150℃/5h (max.) % 6 ASTM F146
    Model fuel B 20℃/5h (max.) % 6 ASTM F146
    색상(Color) Gray
