GAMBIT Gasket

Gambit Compressed Non-Asbestos Sheets & Gasket Model: AF-GL®

Price: Contact

  • Model: AF-GL®
  • Gambit Compressed Non-Asbestos Sheets & Gasket

    Model: AF-GL®



  • Trademark: WOOJUGASPACK
  • Origin: Korea
  • Material:

    • Glass fibers, mineral fibers, KevlarⓇ aramid fibers, + NBR binder

    Characteristic:

    • Specially selected constituents and structure of AF-GL gasket sheet ensure high tightness of a joint and resistance to a whole range of media, including steam, water, fuels, oils, solutions of salt as well as weak solutions of acids and bases.
    • Thanks to application of a unique composition of fibers and fillers, gaskets made of this material feature higher resistance to operation in steam.

    Specifications:

    Maximum Working Conditions
    Peak Temperature 400
    Temperature Under Continuous Operation 340
    Temperature Under Continuous Operation With Steam 250
    최저온도(Min. Peak Temperature) -100
    압력(Pressure) MPa 12
    Physical and Chemical Properties
    Density (±5%) g/cm3 1.9 DIN 28090 - 2
    Transverse Tensile Strength (min.) MPa 9 DIN 52910
    Compressibility (Typical Value) % 10 ASTM F36
    Elastic Recovery (min.63280) % 55 ASTM F36
    Residual Stress 50MPa/16h/300℃ (min.) MPa 29 DIN 52913
    Residual Stress 50MPa/16h/175℃ (min.) MPa 34 DIN 52913
    Increase In Thickness
    Oil IRM 903 150℃/5h (max.) % 6 ASTM F146
    Model fuel B 20℃/5h (max.) % 6 ASTM F146
    Distilled water % 5 ASTM F146
    Color Gray
