Insulation Sets - GRE Material Properties - WOOJU GASPACK

Price: Contact

Model: GRE

Insulation Sets - GRE Material Properties - WOOJU GASPACK

Trademark: WOOJUGASPACK

Origin: Korea

Order

Project details Download Catalogue Evaluate

Material Properties

GRE

Characteristic

Dielectric seal retainer material of insulation gasket is made of NEMA grade G-10 glass-reinforced epoxy(GRE). This material has excellent performance characteristics with very high compressive strength, high flexural strength, high dielectric strength and low fluid absorption. G-10 material is rated for service grade up to 150°C(302°F). For higher temperature service, G-11 material is an acceptable alternative material, which is rated for 200°C(392°F) continuous service.

ASTM	Test Method	G-10 Epoxy/Glass	G-11 Epoxy/Glass
D695	Compressive Strength(psi)	66,000	50,000
D149	Dielectric Strength(VPM)	800	550
D229	Water Absorption(%)	0.05	0.09
D790	Flexural Strength(psi)	65,000	57,000
D638	Tensile Strength(psi)	40,000	41,000
D732	Shear Strength(psi)	21,000	21,000
D256	Impact Strength(ft.lb/in)	26.0	10.0
	Temperature Range (°F)	-200 ~ 302	-50 ~392
	Temperature Range (°C)	-129 ~ 150	-46 ~200
