YPR-41W Type Primary Pressure Regulating Valve for Water 20K

This is a type of relief valve and regulating valve that discharges excessive pressure resulting from load fluctuations and maintains a constant pressure level in instruments or pipelines. It is possible to install this product as a primary pressure regulating valve in
the bypass circuit to relieve excessive pressure, and to adjust the discharge pressure to remain constant.


Features

• A constant pressure level with only a single adjustment.
• Stable operations: no such issues as hunching or vibration.
• Piston-type balance structure: minimal change in the opening pressure resulting from back pressure fluctuations.
• Upper part dissembles in one-way: allows for internal inspection and maintenance.
• Use of a disc made of special materials inside the valve: No water leakage when the valve is opened and closed.


Specifications

• Type: YPR-41W
• Size: 15(½”)~150(6”)
• Structure: Direct operating
• Applicable fluid: Water
• Primary pressure: Below 1.4MPa
• Permissible leakage : 0.01% below rated flow (ANSI b16.104 class IV)
• High pressure regulation : 0.05-1.4MPa
• Maximum pressure : Within desired pressure x Within 20 % (Within 0.03 MPa minimum)
• Accumulated pressure: Within desired pressure x Within 20 % (Within 0.03 MPa minimum)
• Fluid temperature: Below 80°C
• End connection: KS 20K RF FLANGE
• Material:
  • Body: SCPH2
  • Disc, Seat: NBR, STS
  • Diaphragm: NBR
• Hydraulic test pressure: Water pressure
• Options: 1.5 times the Flange pressure

▶ Choose Pilot type valve to relief excessive pressure flow.
▶ Made – to – order for ANSI CLASS V class Permissible leakage products.
▶ Made – to – order for interior coated products.
