YFC-1S Type Constant Flow Control Valve

Auto Flow Control Valve

What is needed for effective and efficient use of heating energy in tandem with the diversification of buildings is enhancing thermal efficiency by automatically controlling the appropriate flow of each piping system and thus supplying precisely based on the designed flow value. Samyang’s type YFC-1 is the most costeffective and practical product that features a wide array of functions as a constant flow control valve.

Features

• Free from troubles, abrasion and corrosion thanks to an extremely simple structure.
• Can be installed in any direction-horizontally, vertically, or acutely and almost no flow changes resulting from the installation direction.
• Offer a wide selection range for the set flow, and maintains an outstanding performance even in case of a water hammer, vibration, or rapid pressure changes.
• Can be easily handled and installation costs are extremely low.


Specification:

• Type: YFC-1S
• Size: 32(1.1/4“) ~ 50 (2”)
• Automatic differential pressure range: 0.02~0.15MPa / 0.03~0.4MPa
• Applicable fluid: Cold/hot water
• Fluid temperature: 120°C below
• Flow variation: ±5.0% of set flow
• End connection: KS PT SCREW
• Material
  • Body: C3604
  • Main part: STS
• Hydraulic test pressure: 1.5MPa

▶ When using a valve, be sure to install a strainer (40MESH or more) at the front end. (60 MESH recommended)
▶ Test Cock can be attached
▶ Custom made for 20kg/cm2
▶ Install in a water pipe instead of a supply pipe
