Deluge Valve with Pressure Reducing Pilot Trim

HD deluge valve can be fitted with a pressure reducing pilot in order to reduce and manage outlet pressure, as per site design requirements.

Description

• Pressure Reducing Pilot trim suitable for Deluge Valve Model H3
• Sizes: 4”, 6” and 8”
• The pressure reducing function maintains pre-set outlet pressure in Deluge Valve
• It automatically reduces a higher inlet pressure to a steady lower outlet pressure, regardless of varying inlet pressure and / or changing flow rate demand
• Hydraulically controlled diaphragm operated pilot valve with highly proven reliable design
• Wide range of downstream pressure can be set by turning the adjustment screw on the pressure control pilot valve (PCP)
