Cryogenic by-passes valve

Price: Contact

  • Model: Cryogenic by-passes valve
  • Cryogenic by-passes
    They are small and housed in the tank tool block. Particularly suitable for applications on differential pressure measurements, they allow for the control of the fluid contained in the system.

    • Available with 3 and 4 valves
    • Possibility of a 40 diameter flange for connection to the control pressure gauge
    • Line or square couplings
    • Centre to centre distance of 35 mm (3, 4 valves) or 35 mm (inlet), 54 mm (outlet) if with 4 valves
    • Conical needle shutter free to rotate with respect to the stem for greater resistance to wear due to rubbing during closing.
  • Trademark: BOSCAROL
  • Origin: Italy
  • Size: DN6.5
    Nominal pressure (NP) 40 bar / 580 psi
    Operating temperature -196°C/-321°F ÷ +50°C/+122°F
    Couplings Male/female threaded: 1/4 NPT, 1/4 BSP, UNF 1)
    Certification Direttiva 94/9/UE (ATEX)
    Materials Body: Stainless steel. A479-grade 304
    Stem: Stainless steel. A479-grade 316
    Pin shutter: Stainless steel A479-grade 316 with stellite insert
    Seal: PTFE Handwheel: bleached brass

    1) Other types of threading on request

    Boscarol's sectors

    A tradition of flexibility and professionalism

    Food, chemical, pharmaceutical, mechanical and much more: the sectors served by Boscarol solutions are various, each one with precise needs that are met by specific products. Production flexibility, competence and high technological performance are the factors allowing us to successfully deal with the most different industries.

    Cryogenic gas containment solutions
    Our low-temperature valves are designed for all companies that produce technical gases or pressure equipment to contain cryogenic gases, such as the oxygen and medical gas production chain. Reducers are devices whose function is to decrease upstream pressure by regulating it downstream to a lower level, keeping it constant. They are used in various sectors such as the dry ice production.

    • Food
    • Environmental
    • Chemical
    • Pharmaceutical
    • Mechanical
    • Metallurgical
    • Glass industry
    • Cement industry
    • Energy sector
    • Metal processing
    • Hospitals
    • Research laboratories
    • Freezing
    • Cooling
    • Packaging

    High temperature fluid handling solutions
    Our gauge valves are designed for applications where high pressures and sudden temperature changes are involved, e.g. the chemical, naval and steel processing sectors. They can be applied to pipes, machines or plants where the flow of supply or discharge fluids must be regulated or interrupted.
