Cryogenic Valves

Cryogenic valves

Price: Contact

  • Model: CRIO/ CRIO 300/ BOSCAROL/ CRIO RITEGNO
  • Boscarol Cryogenic valves
    Functional and easy to maintain, our cryogenic valves guarantee precise pressure control and meet the needs of loading and unloading fluids at very low temperatures while respecting safety margins. Developed for sensitive application needs, they are totally free of any grease traces.
    Technical features

    • Fluid loading and withdrawal up to -196°C
    • Available in diameters from DN 6 to DN 150
    • Available up to nominal pressure PN 40
    • Developed for use in oxygen, nitrogen, argon, carbon dioxide, helium, air distribution and storage systems
    • Available in line or angle
    • Stainless steel


  • Trademark: BOSCAROL
  • Origin: Italy
  • Size: DN8
  • Product table

    Series CRIO CRIO 300 BOSCAROL CRIO RITEGNO
    Nominal diameter (ND) 6 ÷ 50 65 ÷ 150 6 ÷ 40 10 ÷ 50
    Nominal pressure (NP) 40 50 40 40
    Operating temperatures -196°C ÷ +50°C -196°C ÷ +75°C -196°C ÷ +50°C       -196°C ÷ +50°C
    Connections Welded BW/SW, flanged, threaded Welded BW, flanged Threaded Welded BW/SW, flanged, threaded
    Activation Manual or pneumatic Manual or pneumatic Manual -
    Type of sealing Soft Soft Metal Soft
    Material Body A479 gr.304 A351 gr. CF3 A479 gr.304 A479 gr.304
    Bonnet plug A479 gr.304 -CW617N (1) A479 gr.304 CW617N (1) A582 gr.303 -A479 gr.304 -CW617N (1)
    Bonnet A479 gr.304 A479 gr.304 A479 gr.304 -
    Stem A479 gr.304 A479 gr.304 A479 gr.304 -
    Stuffing nut PTFE PTFE PTFE -
    Seal disk 25% glass reinforced PTFE 25% glass reinforced PTFE stellite 25% glass reinforced PTFE
    Reference standards ASME/ANSI: B16.34, B16.11, B16.25, B16.25, B16.5 ; EN 1626 ; ISO 5208
    Certification 94/9/UE (ATEX); 2014/68/UE (PED); 2010/35/UE (T-PED)

    (1) only for threaded collars



    Boscarol's sectors
    A tradition of flexibility and professionalism

    Food, chemical, pharmaceutical, mechanical and much more: the sectors served by Boscarol solutions are various, each one with precise needs that are met by specific products. Production flexibility, competence and high technological performance are the factors allowing us to successfully deal with the most different industries.

    Cryogenic gas containment solutions
    Our low-temperature valves are designed for all companies that produce technical gases or pressure equipment to contain cryogenic gases, such as the oxygen and medical gas production chain. Reducers are devices whose function is to decrease upstream pressure by regulating it downstream to a lower level, keeping it constant. They are used in various sectors such as the dry ice production.

    • Food
    • Environmental
    • Chemical
    • Pharmaceutical
    • Mechanical
    • Metallurgical
    • Glass industry
    • Cement industry
    • Energy sector
    • Metal processing
    • Hospitals
    • Research laboratories
    • Freezing
    • Cooling
    • Packaging

    High temperature fluid handling solutions
    Our gauge valves are designed for applications where high pressures and sudden temperature changes are involved, e.g. the chemical, naval and steel processing sectors. They can be applied to pipes, machines or plants where the flow of supply or discharge fluids must be regulated or interrupted.
