HIGH PERFORMANCE BUTTERFLY VALVE VALUE VF-8

Spec.

• Size: 4″- 48″( DN100-DN1200)
• Temperature Range: -100 °C~550 °C(-148 °F~1022°F)
• Pressure Rating: ANSI 150/300/600/900LB
• VALVE DESIGN & PRESSURE/TEMPERTURE RATINGS:
  -ASME B16.34
  -API 609
• PRESSURE TESTING:
  -API 598
  -ISO 5208
• FLANGE DRILLING:
  -ASME B16.5
  -ASME B 16.47
  -ISO 7005
  -EN 1092
• MOUNTING FLANGE:
  -ISO 5211
  -FACE TO FACE:
  -API 609
  -ISO 5752
  -ASME B16.10
• FIRE SAFE APPROVAL:
  -API 607
  -ISO 10497
• FUGITIVE EMISSION APPROVAL:
  -ANSI/ISA-SP-93
  -ISO15848
  -TA LUFT
• CRYOGENIC:
  -BS 6364
• MARKING:
  -MSS-SP-25
  -ASME B16.34
• LEAKAGE CLASS:
  -ANSI FCI 70-2 Class V
  -ISO 5208 RATE A
• MANUFACTURING QUALITY:
  -ISO 9001
  -PED 2014/68/EU(Module H)
  -ATEX 2014/34/EU
  -SIL 3 (The valves are suitable for use in a safety instrumented system up to SIL 2 -(low demand mode).The valves may be used in a redundant architecture up to SIL 3.)
• CERTIFICATION:
• -API 609 Monogram
  -API 607
  -ISO 15848
  -ISO 10497
  -TR CU 010
  -TR CU 032
