Twin Sphere Rubber Joint - Flanged End - Model Twinflex

• Bellow type: double sphere / twin-sphere / 2 bellow

• Bellow material: synthetic rubber

  • Reinforcing ring: carbon steel

  • Inner rubber: synthetic rubber

  • Outer rubber: synthetic rubber

  • Reinforcing cord: synthetic fiber

• Flange material: Ductile Iron/ SS400/ SS304 / SS316 (option)

• Flange standard: JIS10K/ PN16/ ANSI150 (option)

• Max pressure: 16 kgf/cm2 (16 bar)

• Max temperature: 70 oc

• Model: Twinflex

• Size: 32A ~ 500A (DN32 ~ DN500)

• Brand: TOZEN-JAPAN

• Origin: CHINA

• Status: available in stock

• Delivery: nationwide

Remarks:

• Price will be different if flange material and flange connection standard are different. The price will increase gradually according to the flange material in the order: Ductile iron => SS400 steel => 304 stainless steel => 316 stainless steel and flange standard JIS10K => PN16 => ANSI 150.

Product Information Tozen Double Sphere Rubber Joint

• Tozen rubber flexible joint is one of the outstanding products of Tozen Group.

• Products have been applied in many different projects and systems.

• Couplings are mainly used for connecting pipes together.

• However, they are not just for connecting devices. But it plays an important role in the operation of the system.

• Therefore, rubber couplings possess many outstanding characteristics.

• Currently, Tozen rubber flexible joints provided by our company are always available in stock. If you want to buy, please contact

Product salient features:

Achievements of Rubber Joint:

• Anti-vibration rubber flexible couplings have been used in over 20 countries for more than 30 years.

• Tozen branded products proudly affirm their quality and brand.

• Anti-vibration rubber flexible coupling is a popular product all over the world.

Lifespan of rubber joint

• Lifespan of up to 10 years thanks to TOZEN's special and rigorous design standards.

• All products are manufactured according to the technical process.

• Before being shipped out, they are all quality checked to ensure they meet the standards.

Quality:

• Manufactured at the main factory, TOZEN couplings are strictly controlled by the ISO 9001 quality management system.

• Product quality is certified and applied in many countries around the world.

Durability during testing:

• Passed the recirculation pressure test of 20,000 rounds or more.

Burst pressure:

• 32 ~ 150mm, 5.0 MPa/50bar/50 kg/cm2 at normal temperature.

Application of rubber joint:

• Not everyone knows the applications of anti-vibration rubber joints.

• We usually only know them for connecting industrial piping systems, but what specifically?

• Currently, rubber couplings are used in many different fields.

• From civil to industrial systems, this device is available.

Typical applications of couplings can be mentioned as:

• Products are mainly used for piping systems in buildings, factories, industry, etc.

• Liquids passing through the pipeline system include: water, cold water, warm water, sea water, gas, etc.

• Ventilation, heating, air conditioning systems, cooling systems, chemical plants, etc.

• This product must not be used for the pipeline system of drinking water, swimming pool water, oil.

Structure of double sphere rubber joint:

• Flange: Ductile iron/ Steel SS400/ A105/ SS304/SS316

• Reinforcement ring: Carbon steel

• Clear rubber: Synthetic rubber

• Outer rubber: Synthetic rubber

• Reinforced wire: Synthetic fiber

• Flanges according to JIS10K, ANSI150, PN16 are standard.

For other flanges, please consult us.

Products Tozen double sphere rubber joint are being sold at our company PHUC MINH ENGINEERING. For goods status please contact our sales staff directly.
