SWISSFLUID Valves

SBE - Elastomer seated Butterfly Valve

Price: Contact

  • Model: SBE
  • Elastomer seated Butterfly Valve SBE Swissfluid

    • Status: order
    • Model: SBE
  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Elastomer seated Butterfly Valve SBE

    Soft seated elastomeric Butterfly Valves SBE are available in either wafer or lug design for on/off, throttling or control applications for dilute acids and lyes, powdery media or gaseous service.


    Main features

    • Large selection of different materials and trims
    • Blow-out proof one-piece disc/stem assembly
    • Flow-optimized disc for high cv values
    • Disc features a rated breaking-point outside the atmospheric seal
    • Hysteresis free throttling characteristic
    • Easy installation and maintenance due to split body design
    • ISO mounting flange for direct automation



    Technical data

    Version DIN / ISO ANSI
    Sizes DN40 – DN800 1½" – 32"
    Flanges

    EN 1092-1 B1
    PN10/16
    ASME B16.5 RF
    ANSI 150lbs
    Face to face EN 558-1 series 20 ASME B16.10
    Body Cast steel 1.0619 ASTM A216 WCB
    Liner EPDM, FPM, NBR
    Valve disc 1.4462 Duplex, PFA, PFA-AS encapsulated (conductive)
    Operating conditions (depending on lining material)
    Pressure up to 16 bar
    Temperature -40°C up to +200°C




    Options

    Body Stainless steel casting 1.4408 AISI 316 CF-8M
    Liner SBR, VMQ, CXN, EPDM white
    Valve disc ETFE, PVDF, PP, 1.4462 polished, Titanium Grade 2, Hastelloy C
